| Connector system | φ4mm |
| Rated voltage | 1000V DC(IEC)1 |
| Rated current | 17A(1.5mm2) 22A(2.5mm2, 14AWG) 30A(4mm2, 6mm2, 12AWG, 10AWG) |
| Test voltage | 6KV(50HZ, 1min.) |
| Ambient temperature range | -40C... +90°C(IEC) -40°C... +75°C(UL) |
| Upper limiting temper ature | +105°C(IEC) |
| Degree of protetion, mated | lp67 |
| Unmated | IP2X |
| Comtact rsistanceof plug connectors | 0.5mΩ |
| Safetyclass | Ⅱ |
| Contact material | Messing, verzinnt Copper Alloy, tin plated |
| Insulation material | PC/PV |
| Locking system | Snap-in |
| Flame class | UL-94-V0 |
| Salt mist spray test, degree of severity5 | IEC 60068-2-52 |
